Synchronous Motors | Synchronous Motors in China - Ever-Power Transmission
A synchronous engine is one where the rotor normally rotates at the same velocity as the revolving field in the device. The stator is similar to that of an induction machine comprising a cylindrical iron framework with windings, usually three-phase, located in slots around the internal periphery.
usually, synchronous motors are used for applications where precise and constant speed is required. Low power applications of these motors include positioning devices. These are also used in robot actuators. Ball mills, clocks, record participant turntables also utilize synchronous motors.
The principle of operation of a synchronous engine could be understood by taking into consideration the stator windings to be connected to a three-phase alternating-current supply. The result of the stator current is definitely to determine a magnetic field rotating at 120 f/p revolutions each and every minute for a frequency of f hertz and for p poles. A direct current in a p-pole field winding on the rotor may also produce a magnetic field rotating at rotor acceleration. If the rotor rate is made equal to that of the stator field and there is absolutely no load torque, both of these magnetic fields will tend to align with one another.
As mechanical load is certainly applied, the rotor slips back several degrees with respect to the rotating field of the stator, developing torque and ongoing to become drawn around by this rotating field. The angle between the fields increases as load torque is definitely increased. The utmost available torque is accomplished when the angle where the rotor field lags the stator field is definitely 90°. App of more load torque will stall the motor.
One benefit of the synchronous motor is certainly that the magnetic field of the machine can be made by the direct current in the field winding, so that the stator windings need to provide only a power component of current in stage with the applied stator voltage-i.e., the electric motor can operate at unity power factor. This condition minimizes the losses and heating in the stator windings.
You can also visit our Electric Motor Products
