This short article provides an introduction to the RC Transmitter and RC Receiver Systems you can use with Erle-Brain 2, together with assistance with the way they are connected.

providing an overview of the RC Transmitter and RC Receiver Systems

This short article provides an introduction to the RC Transmitter and RC Receiver Systems you can use with Erle-Brain 2, together with assistance with the way they are connected.

Erle-Brain 2 works with Parts per million-Sum RC receivers. For traditional single-wire-per-funnel (PWM) receivers a Parts per million encoder may be used to convert the receiver outputs to Parts per million-SUM.

Formally supported RCs

Turnigy TGY-i6

This RC receiver includes 6 pin output, one for every Parts per million funnel. As Erle-Brain only accepts Parts per million-Sum input type, conversion from 8 Parts per million funnel to 1 Parts per million-Sum is required.

This conversion is created utilizing a Parts per million Encoder. This module covers the 8 Parts per million channels right into a Parts per million-Sum type, that is based on Erle-Brain.

To learn more begin to see the manual and also the offical documentation.

FlySky TH9x

This RC has 9 channels and it is highly suggested if you want to control a number of optional components (for instance a gimbal or EPM).

To learn more, browse the manual. To be able to connect this module, you simply need to follow this official documentation section.
